The air shovel mainly uses the compressed air provided by the air compressor as the power to make the hammer body in it move back and forth, and strike the shovel bit, so as to realize the chiseling operation of the shovel on metal and building materials. It is mainly used in casting, welding, construction and furnace maintenance. So, what are the characteristics of air shovel? What role does the press play?

氣鏟特點：

Features of air shovel:

1、在采礦工業中該產品用于截斷煤層，打碎軟礦石；

1. In mining industry, the product is used to cut off coal seam and break soft ore;

2、在土木工程、鐵路、公路、碼頭、電站建設中，用于破碎土層鑿洞穿孔，挖掘土方等作業；

2. In the construction of civil engineering, railway, highway, wharf and power station, it is used to drill holes in broken soil layer and excavate earthwork;

3、工作平穩，安 全可靠；

3. The work is stable, safe and reliable;

4、獨特的減振裝置漸進式啟動；

4. The unique shock absorber starts gradually;

5、操作者的舒 適感大大提高，振動感大大降低慢速啟動，更好控制。

5. The comfort of the operator is greatly improved, the vibration is greatly reduced, and the slow start is better controlled.

風鎬是用空壓機壓縮空氣為動力的工具，壓縮空氣由管狀分配閥輪流分配于缸體兩端，使錘體進行往復沖擊運動，使鎬釬打入工作物，致使分 裂成塊。

Pneumatic pick is a tool powered by compressed air of air compressor. Compressed air is distributed at both ends of cylinder body by tubular distribution valve in turn, which makes hammer body carry out reciprocating impact motion, and makes pick drill into work object, resulting in splitting into blocks.

手持的風動工具，用壓縮空氣推動活塞往復運動，使鎬頭不斷撞擊。用于采礦、筑路等。

The hand-held pneumatic tool uses compressed air to push the piston to move back and forth, so that the pick keeps hitting. Used for mining, road construction, etc.

風鎬由配氣機構、沖擊機構和鎬釬等組成。沖擊機構是一個厚壁氣缸，內有一沖擊錘可沿氣缸內壁作往復運動。鎬釬的尾部插入氣缸的前端，氣缸后端裝有配氣閥箱。

The air pick is composed of a valve distribution mechanism, an impact mechanism and a pick drill. The impact mechanism is a thick wall cylinder, in which there is an impact hammer which can move back and forth along the inner wall of the cylinder. The tail of the pickaxe is inserted into the front end of the cylinder, and the rear end of the cylinder is equipped with a valve box.

在氣缸壁的四周有許多縱向氣孔，壓縮柱塞閥的彈簧而接通氣路，這些氣孔一端通配氣閥，推壓手柄套筒，另一端通入氣缸，各氣孔的長度根據沖擊錘的運動要求配置，以便輪流進氣或排氣，柱塞閥在螺旋彈簧作用下處于切斷氣路的常閉狀態。

There are many longitudinal air holes around the cylinder wall, which compress the spring of the plunger valve and connect with the air passage. One end of these air holes is connected with the air distribution valve, push the handle sleeve, and the other end is connected with the cylinder. The length of each air hole is configured according to the movement requirements of the impact hammer, so as to take turns in or out air. The plunger valve is in the normally closed state of cutting off the air passage under the action of the spiral spring.

使沖擊錘在氣缸內有規律地往復運動。沖擊錘向前運動時，錘頭打擊釬尾；沖擊錘向后運動時，氣缸內的氣體封閉在配氣閥箱內，形成柔性緩沖墊層，氣缸內的氣體封閉在配氣閥箱內，待重新配氣后再向前沖擊。錘頭打擊釬尾；沖擊錘向后運動時，風鎬的啟動裝置位于手柄套筒內。在進風管和配氣閥之間有一柱塞閥控制氣路，柱塞閥在螺旋彈簧作用下處于切斷氣路的常閉狀態。

Make the impact hammer move back and forth regularly in the cylinder. When the hammer moves forward, the hammer head strikes the drill tail; When the impact hammer moves backward, the gas in the cylinder is sealed in the valve box to form a flexible cushion. The gas in the cylinder is sealed in the valve box, and it will impact forward after the air is redistributed. Hammerhead striking drill tail; When the impact hammer moves backward, the starting device of the air pick is located in the handle sleeve. A plunger valve controls the air path between the air inlet pipe and the air distribution valve, and the plunger valve is in the normally closed state of cutting off the air path under the action of the spiral spring.

風鎬作業時，使鎬釬頂住施工面，另一端通入氣缸，推壓手柄套筒，壓縮柱塞閥的彈簧而接通氣路，在氣缸壁的四周有許多縱向氣孔，配氣閥隨即自動配氣，氣缸后端裝有配氣閥箱。使沖擊錘不斷往復運動，打擊釬尾，破碎施工體。

When the air pick is working, make the pick against the working face, and connect the other end to the air cylinder. Push the handle sleeve, compress the spring of the plunger valve and connect the air passage. There are many longitudinal air holes around the cylinder wall, and the air distribution valve will automatically distribute air. The air distribution valve box is installed at the rear end of the cylinder. It makes the impact hammer continuously move back and forth to strike the drill tail and break the construction body.
