PSA制氮機出現噴灰現象該如何處理？

制氮機噴灰現象，也被稱之為碳分子篩粉化，這種情況的出現是由于碳分子篩壓不嚴實或碳分子篩松動，造成制氮機噴粉冒黑煙，此時需要整個系統徹底更換碳分子篩。如果此時還是正常添加碳分子篩，就會出現碳分子篩不停地噴出，后果會越來越嚴重，整個氮氣管道系統會有碳分子篩粉末。

The phenomenon of dusting in the nitrogen generator is also known as the pulverization of carbon molecular sieve. This phenomenon is caused by the loose pressure of carbon molecular sieve or the loose of carbon molecular sieve, which causes the black smoke of dusting in the nitrogen generator. At this time, the carbon molecular sieve in the whole system needs to be completely replaced. If the carbon molecular sieve is added normally at this time, the carbon molecular sieve will be continuously ejected, and the consequences will be more and more serious. The whole nitrogen pipeline system will have carbon molecular sieve powder.

制氮機使用過程中受到撞擊或者設備移動等原因?qū)е挛剿Y(jié)構性毛病如吸附塔管道脫焊，碳分子篩外流，碳分子篩松動而粉化。從消音器噴出來的物質一般會有小顆粒，咱們需要查看該顆粒是活性炭還是分子篩。

The structural defects of adsorption tower caused by impact or equipment movement during the use of nitrogen generator, such as desoldering of adsorption tower pipe, outflow of carbon molecular sieve, loosening and pulverization of carbon molecular sieve. The material ejected from the muffler usually has small particles. We need to check whether the particles are activated carbon or molecular sieve.

由于活性炭和分子篩都是黑色的固體顆粒，從色彩上很難分辨，可是他們的顆粒形狀不同。假如噴出來的是活性炭，那么問題還不是很嚴重，咱們可以將活性炭過濾器拆下，去除里面的活性炭，查看活性炭底部絲網是否有破損，如有破損，更換新的不銹鋼絲網，然后裝回活性炭即可正常運轉。

Because activated carbon and molecular sieve are black solid particles, it is difficult to distinguish from each other in color, but their particle shapes are different. If the activated carbon is sprayed out, then the problem is not very serious. We can remove the activated carbon from the activated carbon filter and check whether the screen at the bottom of the activated carbon is damaged. If it is damaged, replace it with a new stainless steel screen, and then replace it with activated carbon.

裝填活性炭的時盡量將過濾器內裝滿，防止活性炭在氣流作用下相互碰擊產生粉塵。假如噴出來的是分子篩，那么處理起來就比較麻煩了，需要將設備運回工廠后進行大修。

When loading activated carbon, try to fill the filter to prevent the activated carbon from colliding with each other under the action of air flow to produce dust. If the jet is molecular sieve, then the treatment is more troublesome, and the equipment needs to be transported back to the factory for overhaul.
